ATP-050-12 Air to Plate Cooling/Heating Unit 56 Watts

Air to Plate Cooling/Heating Unit

• Part Number: ATP-050-12
• 56 Watts of cooling capacity at 0°C delta T.
• Power needed: DC 12 volt, 10.8 amp
• Cold plate dimensions: 80 x 60mm (3.15 x 2.362")
• High performance bonded fin aluminum heat sink
• Overall dimensions: 160 x 124 x 84mm (6.30 x 4.88 x 3.31")
• Weight: 1125 grams (2.48 lbs)


Complete assembly Cold plate for cooling or heating of objects that can be directly mounted to the plate surface.

• Fully assembled ready to connect to power.
• Terminal block for quick and easy electrical connections.
• Fans and TEC power have separate terminals to allow independent control.
• Can be mounted in any orientation.
• Foam insulation to minimize backward heat transfer and reduce noise and vibration.
• Also known as; peltier cold plate thermoelectric cold plate, solid state cold plate.
