WBA-4.0-0.92-CU-01 Water Block 4.0 x 4.0 x 0.92" Copper

Liquid Cold Plate Water Block Assembly

• Part Number: WBA-3.0-0.90-CU-2G
• Overall body dimensions: 3.0 x 3.0 x 0.90" (L x W x H).
• Usable area of 65.0 x 65.0mm (2.56x 2.56 inches).
• Weight: 771gm (1.70 lb)
• 1/4" NPT threaded inlet and outlet.
• Option to add 2 pieces of brass barbed fittings for 1/2" ID tubing.
• CNC machined from solid copper [Alloy CU 110, 99.9% pure Copper] .

Liquid heat exchanger to rapidly remove heat from the hot side of TECs, TEGs, or just about any component. Most efficient method of removing heat from multiple TECs or TEGs.

• Very high surface area internal flow path for maximum heat transfer.
• CNC machined from solid copper.
• Measures: 4.0 x 4.0 x 0.92 inches.
• Usable flat area of 3.54 x 3.54 inches (90 x 90 mm).
• Liquid volume (internal) is XXX ml.
• 10 mounting holes tapped for 6-32 screws.
• Inlet and Outlet on opposite sides.
• 1/4" NPT threaded inlet and outlet.
• Option to add 2 pieces of brass barbed fittings for 1/2" ID Tube.
• Manufactured and assembled in Bishopville, MD U.S.A.

Will accommodate;

• Any object to be cooled up to 90 x 90mm.
• Single TECs or TEGs up to 90 x 90mm.
• 2 to 4 TECs or TEGs up to 40 x 40mm.
• 2 to 8 TECs or TEGs up to 30 x 30mm.

CNC Machined from a solid billet of copper with an O-ring seal. Internal flow path is easily serviceable by removing screws and cover.

This water block has been tested with a heat load of up to 1200 watts. All indications showed that it could handle higher loads.

O-ring material is Buna-N which is capable of fluid temperatures from -29 to +120 C. Alternative o-ring materials are available as an option. Please contact us.
